37
Window
Hanning
Hamming
Rectangular
Blackman
Select FFT window types.
FFT ZOOM
1X
2X
5X
10X
Changes the horizontal
magnification of the FFT display.
Next Page
Page 1/2
Enter the second page of FFT
menu.
Table 3.12 – FFT Function Menu 2
FFT Option
Setting
Description
Scale
Vrms
Set Vrms to be the Vertical Scale
unit.
dBVrms
Set dBVrms to be the vertical
Scale unit.
Display
Split
Full screen
Display FFT waveform on half
screen.
Display FFT waveform on full
screen.
Next Page
Page 2/2
Return to the first page of FFT
menu.
