Slope Trigger
Trigger on positive slope or negative slope of waveform, according to
setup time of the oscilloscope.
Table 3.22 – Slope Trigger Function Menu 1
Option
Setting
Instruction
Type
Slope
Trigger on positive slope of
negative slope according to setup
time of the oscilloscope.
Source
CH1
CH2
EXT
EXT/5
Select trigger source.
When
Select trigger condition.
Time
<Set time>
Turn the “Universal” knob to set
slope time. Time setup range is
20ns-10s.
Next Page
Page 1/2
Enter the second page of slope
trigger.
