BK Precision 2190E User Manual

83
Figure 3.37 – Cursor Menu (Manual)
Track Mode
Table 3.36 – Track Mode Menu
Option
Setting
Description
Cursor Mode
Track
In this mode, set track cursor
measure.
Cursor A
CH1
CH2
NONE
Set the input signal channel that
the Cursor A will measure.
Cursor B
CH1
CH2
NONE
Set the input signal channel that
the Cursor B will measure.
Cur A
Select this option, turn the
“Universal” knob to adjust
horizontal coordinate of Cursor A.
Cur B
Select this option, turn the
“Universal” knob to adjust
horizontal coordinate of Cursor B.
