Page 113
724-746-5500 | blackbox.com
Chapter 4: Configuration
Table 4-19. Network settings.
Field Selection Description
DHCP
Activated
The network settings are automatically supplied by a DHCP server
(default)
Deactivated Function not active
IP address Byte Input of the IP address in the form “192.168.1.1,” if DHCP is not active
Subnet mask Byte
Input of the subnet mask in the form “255.255.255.0,” if DHCP is not
active (default 255.255.255.0)
Gateway Byte
Input of the subnet mask in the form “192.168.1.1,” if DHCP is not
active
API service
Activated
LAN interface at the DKM FX or FXC is activated for access via Java tool
(API service port 5555)
Deactivated Function not active
FTP server
Activated FTP server for tranmission of configuration files activated.
Deactivated Function not active
Syslog
Activated Syslog server for status request is active
Deactivated Function not active
Syslog server Byte Input of the IP address of the Syslog server in the form “192.168.1.1”
Trace
DEB
Activate debug messages in Trace (default: Yes);
NOTE: The debug messages are exclusively for matrix diagnostics. They
only should be activated after consultation with Black Box. Otherwise,
increased traffic of data might limit the performance of the CPU board.
INF Activate information messages in Trace (default: Yes)
NOT Activate notification messages in Trace (default: Yes)
WAR Activate warning messages in Trace (default: Yes)
ERR Activate error messages in Trace (default: Yes)
Syslog
DEB
Activate debug messages in Syslog (default: Yes);
NOTE: The debug messages are exclusively for matrix diagnostics. They
only should be activated after consultation with Black Box. Otherwise,
increased traffic of data might limit the performance of the CPU board.
INF Activate information messages in Syslog (default: Yes)
NOT Activate notification messages in Syslog (default: Yes)
WAR Activate warning messages in Syslog (default: Yes)
ERR Activate error messages in Syslog (default: Yes)
