Page 125
724-746-5500 | blackbox.com
Chapter 4: Configuration
4.5.3 User Macros
User macros can be created to switch or disconnect CON units to CPU units, using
different access rights. The macro commands are created for each user or CON
separately.
A macro can execute up to 16 switching commands successively.
You will use hotkeys and the function keys <F1>-<F16> to execute the
macros.
NOTE: To execute user macros, the user has to be logged in at the matrix.
You can select between the following settings:
Table 4-27. Settings.
Field Selection Description
Function (01–06)
Connect,
(P1 = CON, P2 = CPU)
Set bidirectional connection from console P1 to CPU P2.
Connect Video,
(P1 = CON, P2 = CPU)
Set video connection from console P1 to CPU P2.
Disconnect (P1=CON) Disconnect console P1.
Logout User Logout current user.
Set Real CPU
(P1 = VCPU, P2 = RCPU)
Assign a virtual CPU to a real CPU.
Set Virtual CON
(P1 = RCON, P2 = VCON)
Assign a real console to a virtual console.
Push (P1 = CON)
The individual KVM connection is forwarded to console
P1 and is changed to a video-only connection.
Push Video (P1 = CON)
The video signal of the current connection (KVM or video
only) is forwarded to console P1. The individual connec-
tion remains unchanged (KVM or video only).
Get (P1 = CON)
The individual console gets a video-only connection to
the CPU that is currently connected to console P1. The
connection of console P1 remains unchanged (KVM or
video only).
P1 CON or CPU Device Name of CON or CPU device.
P2 CPU or CON Device Name of CON or CPU device.
