Chapter 2: Overview
2.5.9 ServSwitch DKM FX Compact 32-Port (ACXC32)
1 2 3 4
Figure 2-12. Front view, ACXC32.
Table 2-14. ACXC32 components.
Number Component
1 I/O ports 1–16 (CATx)
2 I/O ports 17–32 (CATx)
3 Serial connection (RJ-45)
4 Network connection (RJ-45)
1 2 3
Figure 2-13. Back view, ACXC32.
Table 2-15. ACXC32 back-panel components.
Number Component
1 Power supply unit 1
2 Power supply unit 2
3 Grounding
