Chapter 5: Operation
To shut down an I/O board:
1. Select “Configuration > Shut Down I/O Board” in the main menu.
2. Press “Okay” to confirm the selection.
The I/O board will shut down.
5.11 Summary of Keyboard Commands
Use the hotkeys described in the following tables to activate extender and matrix
functions.
Table 5-8. Extender commands.
Keyboard Command Description
<hotkey> <a> Download the DDC information of the monitor
connected to the CON unit into the CPU unit.
<hotkey> <k> <1>
<Enter>
Switch to the KVM connection (only with HDMI CON
units with available connection for a local source).
<hotkey> <k> <2>
<Enter>
Switch to the KVM connection 2 (only with HDMI CON
units with available connection for a local source and a
redundant interconnection).
<hotkey> <l> <Enter> Switch to the local source (computer, CPU) (only with
HDMI CON units with available connection for a local
source).
<hotkey> <h> <w>
<Enter>
USB-HID ghosting: Write the descriptions of the input
devices connected to the CON unit into the CPU unit,
and activate the emulation in the CPU unit.
<hotkey> <h> <e>
<Enter>
Activate the emulation of already-stored device
descriptions in the CPU unit.
<hotkey> <h> <d>
<Enter>
Deactivare the emulation of active device descriptions
in the CPU unit. The input devices are now passed
transparently to the source (computer, CPU).
<hotkey> <h> <r>
<Enter>
Deactivate the emulation of active device descriptions
in the CPU unit, and delete the descriptions in the CPU
unit. The input devices are now passed transparently to
the source (computer, CPU).
Go to the next page for Matrix commands.
