Chapter 2: Overview
2.6.6 Firmware Status Matrix
The current firmware status of the installed boards is shown in this menu.
You can access the menu via OSD or Java:
Figure 2-47. OSD and Java icons.
Figure 2-48. Menu status—firmware.
Table 2-49. Menu status—firmware.
Field Description
Name Description of the modules
Type Type number
Ports Number of ports
Version Complete description of the firmware version
Date Date of the firmware version
Status Module status
