Page 62
724-746-5500 | blackbox.com
Chapter 2: Overview
Java Tool
1. Select Status > Matrix Firmware in the task area.
Figure 2-49. Menu Status—Matrix Firmware.
2. To read the firmware status and store it locally (file extension .dtf), select
“Switch > Save Firmware Status to File....”
3. To read the overall status of the ServSwitch DKM FX and store it locally (file
extension .zip), select “Switch > Save Status to File...”, or press the respective
button in the symbol bar.
The various modules can expanded and retracted in the “Name” column by
clicking the left-mouse button on the plus or minus symbols to get a better
overview.
Click on the plus/minus symbol in the upper right corner of the working area
to expand and retract all module information with one click of the left-mouse
button.
