Black Box ServSwitch DKM FX User Manual

Page 208
724-746-5500 | blackbox.com
Chapter 6: Serial Control
Example:
Input port’s request for output Port 160
0x1B 0x5B 0x42 0x07 0x00 0xA0 0x00
Table 6-3. Return of input port for output port.
Bytes Description Coding
1 Control character 0x1B
1 Server indentification 0x5B
1 Command 0x42
2 Requested output port (binary, 1…max. ports) 0x01 0x00 (for Port 1) to 0x120 0x00 (for Port 288)
2 Assigned input port (binary, 1…max. ports) 0x01 0x00 (for Port 1) to 0x120 0x00 (for Port 288)
Example:
Input Port 17’s return for output Port 160
0x1B 0x5B 0x42 0x09 0x00 0xA0 0x00 0x11x00
Table 6-4. Connection of input port with output port.
Bytes Description Coding
1 Control character 0x1B
1 Server identification 0x5B
1 Command 0x43
2 Total length of telegram (9 bytes, binary) 0x09 0x00
2 Requested output port (binary, 1…max. ports) 0x01 0x00 (for Port 1) to 0x120 0x00 (for Port 288)
2 Assigned input port (binary, 1…max. ports) 0x01 0x00 (for Port 1) to 0x120 0x00 (for Port 288)
