Black Box ServSwitch DKM FX User Manual

Page 217
724-746-5500 | blackbox.com
Chapter 6: Serial Control
Table 6-22. Connection of CON (input) with CPU (output)
and CPU (input) with CON (output).
Bytes Description Coding
1 Control character 0x1B
1 Server identification 0x5B
1 Command 0x55
2
Total length of telegram
(9 bytes, binary)
0x09 0x00
2 Requested CPU 0x01 0x00 (for 1 CPU) to 0x11F 0x00 (for 287 CPUs)
2 Requested console 0x01 0x00 (for Console 1to 0x11F 0x00 (for Console 287)
Example:
Connection of Console 23 (input) with CPU 43 (output)
0x1B 0x5B 0x55 0x09 0x00 0x2B 0x00 0x17 0x00
Table 6-23. Connection of CON (input) with CPU (output)
and CPU (input) with CON (output) with a fixed CPU number.
Bytes Description Coding
1 Control character 0x1B
1 Server identification 0x5B
1 Command 0x56
2 Total length of telegram (7 bytes, binary) 0x07 0x00
2 Total number of CPUs 0x01 0x00 (for 1 CPU) to 0x11F 0x00 (for 287 CPUs)
Example:
Connection of Console 23 with CPU 43 and Console 24 with CPU 44 with 50
existing CPUs
0x1B 0x5B 0x56 0x07 0x00 0x32 0x00 0x2B 0x00 0x17 0x00 0x2C 0x00
0x18 0x00
