Chapter 2: Overview
The symbol in Table 2-42 indicates the extender that is recognized and defined at
a certain port.
Table 2-42. Extender recognized.
Symbol Description
Port connected to a CPU unit
Port is connected to a CPU unit that is switched to a CON unit in Private Mode
(see Section 3.7.3).
Port connected to a CON unit
Port connected to a CON unit with Shared Access to a CPU.
Port is connected to a CON unit that is connected to a CPU unit in Private Mode
(see Section 3.7.3).
Port connected to a USB 2.0 CPU unit
Port connected t a USB 2.0 CON unit
Port is configured as a CON port for customer-specific applications.
Port is configured as a CPU port for customer-specific applications.
• Red framed ports are defined as “fixed” (for example, for USB 2.0 connections).
• The port with four static blue squares is currently selected.
• If a port is selected, all the other ports will be shown transparently, except for
those ports that are connected to the currently selected port. To clear a selected
port, press the “Clear Selection” button.
