Page 94
724-746-5500 | blackbox.com
Chapter 4: Configuration
The default settings parameters are:
Table 4-8. Default settings.
Option Description
IP/Hostname Default IP address of the matrix required for connection.
User Default user name used for connection.
Configuration Directory Default directory for configuration files.
Firmware Directory Default directory for update files.
Status Directory Default directory for the firmware status.
Import/Export Directory Default directory for import and export files.
Presets Directory Default directory for macro files.
To set various font sizes for the Java tool, proceed as follows:
1. Select “Extras > Options” in the menu bar.
2. Open the Font tab.
3. Select the desired font size (normal or large).
Report
The Java tool is equipped with a report function that shows the current switching
status and all relevant parts of the matrix configuration in a PDF file.
To create a report, proceed as follows:
1. Select “File > Report...” in the menu bar. A selection assistant will be opened.
2. Select those contents that should be included in the report (Matrix View,
EXT Units, CPU Devices, CON Devices, and Users) and confirm with the
“Next >” button.
3. Select the preferred location for storage of the report and confirm with the
“Finish” button.
The report will be created as a PDF file.
