ACM200 USER MANUAL
03contact support@blustream.co.uk / support@blustream.com.au
Introduction
Impotant Note:
The Blustream Multicast system distributes HDMI video over Layer 3 Managed network hardware. It is advised that
Blustream Multicast devices are connected on an independent network switch to prevent unnecessary interference,
or reduction in signal performance due to other network devices bandwidth requirements.
Please read and understand the instructions in this manual and ensure that the network switch is configured
correctly prior to connecting any Blustream Multicast devices. Failure to do so could result in problems with
configuration of the system and video performance.
• Web interface module for configuration and control of the Blustream Multicast system
• Intuitive 'Drag & Drop' source selection with video preview feature for active monitoring of system status
• Advanced signal management for independent routing of Video, Audio, IR, RS-232, USB/KVM & CEC.
• Auto system configuration
• 2x RJ45 LAN connections to bridge existing network to Multicast video distribution network, resulting in:
- Better system performance as network traic is separated
- No advanced network setup required
- Independent IP address per LAN connection
- Allows simplified TCP / IP control of Multicast system
• RS-232 integration for control of Multicast system
• IR integration for control of Multicast system
• PoE (Power over Ethernet) to power ACM200 from PoE switch
• Local 12V power supply (optional) should switch not support PoE
• Support for iOS and Android App control (not available at initial release)
• 3rd party drivers available for major home control brands
The Blustream UHD Multicast distribution platform allows distribution of HDMI video over a 1Gb Network switch.
The ACM200 Control Module allows advanced third party control of the Multicast system using TCP / IP, RS-232 and
IR.
The ACM200 includes a web interface module for control and configuration of the Multicast system and features
'Drag & Drop' source selection with media preview and independent routing of Video, Audio, IR, RS-232, and USB /
KVM.
Pre-built Blustream device drivers simplify Multicast installation and negate the need for an understanding of
complex network infrastructures.
Features
