DISPLAY (MODEL DEPENDENT)
1 3
2 4
5
ALL INTERIOR LIGHTS
ALL EXTERIOR LIGHTS
INTERIOR & EXTERIOR
WATER PUMP
MAIN A/C
1. Page Navigation Button
Move between function screens, eg. From Tanks to Water screen.
2. Menu Navigation Button
Navigate between items within a page, e.g. in the Water page move from
Pump to Elec Heater.
3-4. Action Buttons
The function for each of the action buttons changes depending on the
selected menu item. These functions will be displayed on the screen, eg.
OK, EXT, RET, On, Off.
5. Redundancy Buttons
Turn lights and water pump on or off. The climate button takes you to the
main climate page.
Adjusting the Lights
QUICK press toggles between off and the previous stored brightness.
LONG press sets the light brightness to 100%.
DESCRIPTION OF PARTS
10
