Warnings, overview
Warning and telltale
lights
Warning symbols in the
display
Meaning
lights up yellow appears on the
display
Electronic immobiliser active ( 31)
lights up red appears on the
display
Serious fault in high-voltage battery unit
( 31)
lights up yellow appears on the
display
Fault in high-voltage battery unit ( 31)
lights up red appears on the
display
Charging cable connected with opera-
tional readiness switched on ( 31)
lights up yellow appears on the
display
Electric drive in emergency operating
mode ( 32)
lights up red appears on the
display
Fault in electric drive ( 32)
lights up yellow
Insulation fault in the high-voltage sec-
tion ( 32)
lights up red
High-voltage safety connector not con-
nected ( 32)
3
28
z Status indicators
