10.0 Spare Parts List with Visual References
Item
#
Part Number
Description
1
422590-C
Stepper Motor & 20 drive pulley
2
P50-1003
Drive Belt, 102T (for 300dpi)
3
423760-FSP-1-C
Platen complete
4
424008-C
Cutter Assembly (BC5) Complete
5
423793
Energy Star Decal
6
422557-25
Cable, Thermal Head
7
423842Z-P1
Electronics Cover,
8
PS46
Switch, For power supply 424009-L
9
424009-L
Power Supply 24VDC (65W)
10
FAA46-FDIO
Main Logic Board (FAA-FDIO)
11
420881P-1A
LCD Cover only
11A
LCD-FAA
LCD Display only
11B*
CPANEL2
Control panel board (LCD is connected to this board)
12
423480C
Upper Exit Deflector ONLY BC5
12A
422718WV
Anti-Static Brush (only)
13
420880P-2-FAA
Cabinet Base, FAA-FDIO
14
423192
Ground Strap
15
423496-5
Head mounting plate
16
423236P
Cam lock lever
17
422589-20
Cable, LCD
18
SQ OPTO-L
SQ Load Opto
19
3003
Print Head
20
424061-FAA
Print Cage Pulley Cover
21
423843-FAA
Power Board Mounting Bracket
22
424052
Buzzer
23
423938
DC Harness, cutter
24
420881Z-FAA
Cover
25
422113Z-FAA
Input hopper
26
422113Z-FSP
Exit Hopper
27
420881Z-FAA-1
Paper Guide Cover
28*
SQ OPTO
SQ Cut Opto
*
423635
Rubber Feet on bottom of printer
*
P19-1000
Cable, AC cord 110VAC (US)
* Not shown in photos
