The following is a brief overview of some representative Menu options:
BAUD RATE? Controls the serial interface baud rate, parity bit, data bits and stop bits.
Here are the following choices:
MINI/MICRO? Defines the type of printer.
MINI Is for a printer with a Silent Cutter Assembly (SC2) (Mini, Mini Plus, Mini MB, Dual Mini)
MICRO Is for a printer without a SC2 (Micro, Micro Plus, Micro MB, Dual Micro)
PRINT SPEED? Controls the speed the ticket travels at. Also effects the print quality. Printer should not be run at a print speed of 0
as it may cause ticket jams. The numbers range from 0 - FASTEST to 7 - SLOWEST. 3 is factory default.
DIAGNOSTIC MODE? Your choices are YES or NO. NO is factory default. (Please consult your Programming Guide)
TICKET TYPE? Factory setting. Do not modify.
STATUS ENABLED? Sets status response protocols.
NONE
Disables the XON/XOFF and status response protocols
SERIAL
Enables the XON/XOFF and status response protocol for the serial port.
PARALLEL
Enables bi-directional parallel status responses if printer is configured as bi-directional.
SER/PAR
Enables both bi-directional parallel and serial status responses.
USB
Enables USB status responses
USB/SER
Enables USB and serial status responses
USB/PAR
Enables USB and bi-directional parallel
USB/SER/PAR
Enables USB, bi-directional parallel and serial status responses
TRANSPARENT MODE? YES (Enabled) or NO (Disabled). (Please consult your Programming Guide)
PAPER MODE? Is generally used only for test purposes. It may also be used on roll stock with no black marks on the ticket. Your
choices are YES (Enabled) ,NO (Disabled) or RECEIPT (for Lemur-R printer only). NO is factory default.
SPECIAL HEAD? Is used when a special paper path size is installed (2.125”, 2.5”, 2.7”….)
Here are the following choices: This feature is set at the factory.
NO
DUAL & SINGLE PATH PRINTER WITH RADW paper guide set to 3.25” & RADJ4 paper guide set to 4”
ON P1
DUAL & SINGLE PATH PRINTER ONLY (Not used for a Lemur series printer)
ON P2
DUAL PATH PRINTER ONLY on path #2 (Not used for a Lemur series printer)
ON BOTH
DUAL PATH PRINTER ONLY on both paths (Not used for a Lemur series printer)
REV ADJ2 P1
DUAL & SINGLE PATH PRINTER WITH RADW or RDJW4 paper guide set to 2”
REV ADJ2 P2
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 2” on path #2
REV ADJ2 BOTH
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 2” on both paths
REV ADJ2.5 P1
DUAL & SINGLE PATH PRINTER WITH RADW or RDJW4 paper guide set to 2.50”
REV ADJ2.5 P2
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 2.50” on path #2
REV ADJ2.5 BOTH
DUAL PATH PRINTER WITH REV RADW or RDJW4 paper guide set to 2.50” on both paths
REV ADJ2.7 P1
DUAL & SINGLE PATH PRINTER WITH RADW or RDJW4 paper guide set to 2.70”
REV ADJ2.7 P2
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 2.70” on path #2
REV ADJ2.7 BOTH
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 2.70” on both paths
REV ADJ3 P1
DUAL & SINGLE PATH PRINTER WITH RADW or RDJW4 paper guide set to 3”
REV ADJ3 P2
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 3” on path #2
REV ADJ3 BOTH
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 3” on both paths
REV ADJ2.125 P1
DUAL & SINGLE PATH PRINTER WITH RADW or RDJW4 paper guide set to 2.125”
REV ADJ2.125 P2
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 2.125” on path #2
REV ADJ2.125 BOTH
DUAL PATH PRINTER WITH RADW or RDJW4 paper guide set to 2.125” on both paths
REV ADJ3.25 P1
DUAL & SINGLE PATH PRINTER WITH RADJ4 ONLY paper guide set to 3.25”
REV ADJ3.25 P2
DUAL & SINGLE PATH PRINTER WITH RADJ4 ONLY paper guide set to 3.25” on path #2
REV ADJ3.25 BOTH
DUAL & SINGLE PATH PRINTER WITH RADJ4 ONLY paper guide set to 3.25” on both paths
CLEAR DOWNLOAD? Clears those items downloaded by the operator to Flash memory.
Your choices are YES or NO.
1200,N,8,1
4800,N,8,1
19200,N,8,1
38400,E,7,1
1200,E,7,1
4800,E,7,1
19200,E,7,1
57600,N,8,1
1200,O,7,1
4800,O,7,1
19200,0,7,1
57600,E,7,1
2400,N,8,1
9600,N,8,1
28800,N,8,1
115200,N,8,1
2400,E,7,1
9600,E,7,1
28800,E,7,1
115200,E,7,1
2400,O,7,1
9600,0,7,1
38400,N,8,1
