737 Operations Manual
Performance Inflight -
General
737-400/CFM56-3_23.5K
Copyright © The Boeing Company. See title page for details.
PI.20.16 D6-27370-400E-TBCE
ADVISORY INFORMATION
Slippery Runway Takeoff (22K Derate)
Weight Adjustment (1000 KG)
V1(MCG) Limit Weight (1000 KG)
22K DERATE
FIELD/OBSTACLE
LIMIT WEIGHT
(1000 KG)
REPORTED BRAKING ACTION
GOOD MEDIUM POOR
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
68 -0.5 -0.5 -0.5 -4.4 -4.4 -4.4 -7.1 -7.1 -7.1
64 -0.7 -0.7 -0.7 -4.2 -4.2 -4.2 -7.0 -7.0 -7.0
60 -1.0 -1.0 -1.0 -4.1 -4.1 -4.1 -6.7 -6.7 -6.7
56 -1.1 -1.1 -1.1 -4.1 -4.1 -4.1 -6.4 -6.4 -6.4
52 -1.3 -1.3 -1.3 -4.1 -4.1 -4.1 -6.0 -6.0 -6.0
48 -1.3 -1.3 -1.3 -3.9 -3.9 -3.9 -5.4 -5.4 -5.4
44 -1.1 -1.1 -1.1 -3.5 -3.5 -3.5 -4.7 -4.7 -4.7
40 -0.8 -0.8 -0.8 -2.9 -2.9 -2.9 -3.9 -3.9 -3.9
36 -0.5 -0.5 -0.5 -1.9 -1.9 -1.9 -2.8 -2.8 -2.8
ADJUSTED
FIELD
LENGTH
(FT)
REPORTED BRAKING ACTION
GOOD MEDIUM POOR
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
3800 31.6
4200 42.1
4600 52.6 36.8
5000 62.9 47.3 31.6 33.2
5400 73.2 57.8 42.1 40.9 29.4
5800 68.0 52.6 48.5 37.1
6200 62.9 56.3 44.7 33.2 31.4
6600 73.2 64.4 52.3 40.9 36.1
7000 72.5 60.3 48.5 40.9 29.1
7400 68.4 56.3 45.9 33.8
7800 64.4 51.1 38.5
8200 72.5 56.6 43.3 31.4
8600 62.3 48.5 36.1
9000 68.2 53.8 40.9
9400 74.3 59.4 45.9
9800 65.3 51.1
10200 71.3 56.6
10600 62.3
11000 68.2
11400 74.3
1. Enter Weight Adjustment table with reported braking action and 22K derate dry field/obstacle limit
weight to obtain slippery runway weight adjustment.
2. Adjust “Good” field length available by -99ft/+99ft for every 5°C above/below 4°C
Adjust “Medium” field length available by -99ft/+99ft for every 5°C above/below 4°C
Adjust “Poor” field length available by -135ft/+135ft for every 5°C above/below 4°C
3. Find V1(MCG) limit weight for temperature adjusted field length and pressure altitude.
4. Max allowable slippery runway limited weight is lesser of weights from 1 and 3.
