737 Operations Manual
Performance Inflight -
General
737-400/CFM56-3_23.5K
Copyright © The Boeing Company. See title page for details.
D6-27370-400E-TBCE PI.20.15
ADVISORY INFORMATION
Slush/Standing Water Takeoff (22K Derate)
Weight Adjustment (1000 KG)
V1(MCG) Limit Weight (1000 KG)
V1 Adjustment (KIAS)
22K DERATE
FIELD/OBSTACLE
LIMIT WEIGHT
(1000 KG)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
68 -7.6 -8.1 -8.6 -9.5 -9.9 -9.7 -13.8 -13.7 -12.3
64 -7.2 -7.8 -8.1 -8.7 -9.5 -9.7 -12.3 -13.2 -13.1
60 -6.6 -7.4 -7.9 -7.9 -8.8 -9.5 -10.9 -12.5 -13.1
56 -6.0 -6.8 -7.5 -7.1 -8.1 -9.0 -9.5 -11.4 -12.7
52 -5.3 -6.2 -7.0 -6.2 -7.3 -8.5 -8.1 -10.1 -11.8
48 -4.6 -5.4 -6.3 -5.3 -6.4 -7.5 -6.8 -8.6 -10.4
44 -3.8 -4.5 -5.2 -4.3 -5.2 -6.3 -5.4 -6.8 -8.6
40 -3.0 -3.6 -4.2 -3.4 -4.1 -4.8 -4.2 -5.0 -6.8
36 -2.0 -2.4 -2.7 -2.2 -2.6 -3.1 -3.0 -3.2 -5.0
ADJUSTED
FIELD
LENGTH
(FT)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
4600 32.1
5000 30.2 33.0 38.3 32.1
5400 37.0 29.2 40.0 32.4 44.7 37.2 31.5
5800 43.6 34.8 28.7 46.7 37.9 31.5 50.9 42.3 35.8
6200 49.9 40.4 33.2 52.9 43.3 36.2 56.4 47.4 40.0
6600 56.7 45.8 37.7 59.3 48.7 40.8 62.0 52.3 44.4
7000 63.2 51.4 42.1 66.3 54.3 45.2 67.6 57.3 48.9
7400 70.2 56.9 46.8 73.3 59.9 49.9 73.1 62.1 53.3
7800 62.5 51.8 65.3 54.7 66.9 57.9
8200 68.7 56.6 71.4 59.5 71.8 62.5
8600 75.0 61.6 64.6 67.0
9000 66.7 69.4 71.6
9400 71.7 74.1
1. Enter Weight Adjustment table with reported braking action and 22K derate dry field/obstacle limit
weight to obtain slippery runway weight adjustment.
2. Adjust field length available by -126ft/+126ft for every 5°C above/below 4°C
3. Find V1(MCG) limit weight for temperature adjusted field length and pressure altitude.
4. Max allowable slippery runway limited weight is lesser of weights from 1 and 3.
WEIGHT
(1000 KG)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
68 -11 -10 -8 -6 -5 -5 2 1 -2
64 -13 -11 -9 -7 -6 -6 2 1 -1
60 -15 -13 -11 -9 -7 -6 2 1 -1
56 -17 -15 -12 -11 -9 -7 2 2 0
52 -18 -16 -14 -14 -11 -8 -1 1 0
48 -20 -18 -15 -16 -13 -9 -5 0 1
44 -21 -20 -17 -18 -15 -11 -10 -3 1
40 -22 -20 -18 -19 -17 -13 -14 -7 0
36 -22 -21 -19 -20 -18 -15 -15 -11 -3
1. Obtain V1, VR and V2 for the actual weight.
2. If V1(MCG) limited, set V1 = V1(MCG). If not V1(MCG) limited, enter V1 Adjustment Table with the
actual weight to obtain V1 speed adjustment. If adjusted V1 is less than V1(MCG), set V1 = V1(MCG).
June 07, 2002
