737 Operations Manual
Performance Inflight -
General
737-300/CFM56-3_22K
Copyright © The Boeing Company. See title page for details.
D6-27370-400E-TBCE PI.10.13
ADVISORY INFORMATION
Slush/Standing Water Takeoff (20K Derate)
Weight Adjustment (1000 KG)
V1 (MCG) Limit Weight (1000 KG)
V1 Adjustment (KIAS)
20K DERATE
FIELD/OBSTACLE
LIMIT WEIGHT
(1000 KG)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
68 -7.6 -7.8 -8.2 -9.4 -9.4 -9.4 -12.4 -12.8 -13.5
64 -7.3 -7.6 -8.2 -8.9 -9.4 -9.8 -12.1 -12.9 -12.9
60 -6.6 -7.2 -7.8 -7.9 -8.8 -9.5 -10.9 -12.1 -12.4
56 -5.9 -6.6 -7.3 -6.8 -7.8 -9.0 -9.4 -11.0 -12.0
52 -5.2 -6.0 -6.6 -6.0 -7.0 -8.2 -8.2 -9.6 -11.3
48 -4.6 -5.2 -6.0 -5.2 -6.2 -7.3 -7.0 -8.2 -10.2
44 -3.9 -4.5 -5.2 -4.5 -5.1 -6.4 -5.9 -6.7 -8.3
40 -3.2 -3.5 -4.4 -3.8 -4.3 -5.0 -4.4 -4.7 -6.3
36 -2.6 -2.4 -3.5 -3.2 -3.5 -3.7 -2.9 -2.5 -4.3
ADJUSTED
FIELD
LENGTH
(FT)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
4600 30.1 34.0
5000 33.9 36.6 40.5 30.8
5400 40.6 29.5 43.1 32.4 46.9 36.3 30.2
5800 47.2 35.0 29.2 49.6 37.9 31.5 53.3 41.8 35.3
6200 53.9 40.5 33.9 56.1 43.4 36.3 60.0 47.3 40.3
6600 60.5 46.1 38.6 62.5 48.9 41.1 66.7 52.6 45.5
7000 67.2 51.6 43.3 69.0 54.4 46.0 73.4 58.1 50.5
7400 73.8 57.2 48.0 75.5 59.9 50.8 63.6 55.7
7800 62.9 52.7 65.4 55.7 69.1 60.9
8200 68.5 57.4 70.9 60.6 74.6 66.1
8600 74.1 62.1 65.5 71.3
9000 66.9 70.4
9400 71.6 75.3
1. Enter Weight Adjustment table with slush/standing water depth and 20K derate dry field/obstacle limit
weight to obtain slush/standing water weight adjustment.
2. Adjust field length available by -108ft/+108ft for every 5°C above/below 4°C.
3. Find V1(MCG) limit weight for temperature adjusted field length and pressure altitude.
4. Max allowable slush/standing water limited weight is lesser of weights from 1 and 3.
WEIGHT
(1000 KG)
SLUSH/STANDING WATER DEPTH
3mm (0.12 INCHES) 6mm (0.25 INCHES) 13mm (0.50 INCHES)
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
68 -9 -9 -8 -3 -5 -6 4 0 -4
64 -11 -11 -9 -5 -6 -6 3 1 -2
60 -13 -13 -11 -6 -7 -6 3 2 0
56 -15 -14 -12 -9 -8 -7 2 2 0
52 -17 -16 -14 -12 -11 -7 0 1 1
48 -19 -18 -15 -15 -13 -9 -3 0 1
44 -21 -20 -16 -17 -15 -11 -7 -3 1
40 -21 -21 -18 -19 -17 -13 -11 -8 0
36 -21 -21 -19 -19 -18 -15 -15 -11 -3
1. Obtain V1, VR and V2 for the actual weight.
2. If V1(MCG) limited, set V1 = V1(MCG). If not V1(MCG) limited, enter V1 Adjustment Table with the
actual weight to obtain V1 speed adjustment. If adjusted V1 is less than V1(MCG), set V1 = V1(MCG).
December 07, 2001
