737 Operations Manual
Performance Inflight -
General
737-300/CFM56-3_22K
Copyright © The Boeing Company. See title page for details.
PI.10.14 D6-27370-400E-TBCE
ADVISORY INFORMATION
Slippery Runway Takeoff (20K Derate)
Weight Adjustment (1000 KG)
V1 (MCG) Limit Weight (1000 KG)
20K DERATE
FIELD/OBSTACLE
LIMIT WEIGHT
(1000 KG)
REPORTED BRAKING ACTION
GOOD MEDIUM POOR
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
68 0.0 0.0 0.0 -3.6 -3.6 -3.6 -7.5 -7.5 -7.5
64 -0.2 -0.2 -0.2 -3.9 -3.9 -3.9 -7.3 -7.3 -7.3
60 -0.6 -0.6 -0.6 -4.0 -4.0 -4.0 -6.9 -6.9 -6.9
56 -0.8 -0.8 -0.8 -3.9 -3.9 -3.9 -6.6 -6.6 -6.6
52 -1.1 -1.1 -1.1 -3.8 -3.8 -3.8 -6.3 -6.3 -6.3
48 -1.1 -1.1 -1.1 -3.7 -3.7 -3.7 -5.9 -5.9 -5.9
44 -0.8 -0.8 -0.8 -3.1 -3.1 -3.1 -5.3 -5.3 -5.3
40 -0.3 -0.3 -0.3 -2.6 -2.6 -2.6 -4.5 -4.5 -4.5
36 0.0 0.0 0.0 -2.0 -2.0 -2.0 -3.6 -3.6 -3.6
ADJUSTED
FIELD
LENGTH
(FT)
REPORTED BRAKING ACTION
GOOD MEDIUM POOR
PRESS ALT (FT) PRESS ALT (FT) PRESS ALT (FT)
S.L. 4000 8000 S.L. 4000 8000 S.L. 4000 8000
3800 36.3
4200 46.4 29.2
4600 56.6 39.3 28.5
5000 66.1 49.6 32.3 36.7
5400 75.7 59.4 42.3 44.8 30.9
5800 69.0 52.7 52.8 39.2 30.5
6200 62.3 59.1 47.1 33.4 35.6
6600 71.9 65.0 55.0 41.6 40.8
7000 70.8 60.9 49.5 46.2 32.0
7400 66.7 56.8 51.9 37.2
7800 72.6 62.6 57.8 42.4 28.4
8200 68.5 63.6 47.9 33.6
8600 74.3 69.5 53.7 38.8
9000 75.4 59.6 44.0
9400 65.4 49.6
9800 71.3 55.5
10200 61.3
10600 67.2
11000 73.0
1. Enter Weight Adjustment table with reported braking action and 20K derate dry field/obstacle limit
weight to obtain slippery runway weight adjustment.
2. Adjust "Good" field length available by -90ft/+90ft for every 5°C above/below 4°C
Adjust "Medium" field length available by -90ft/+90ft for every 5°C above/below 4°C
Adjust "Poor" field length available by -117ft/+117ft for every 5°C above/below 4°C
3. Find V1(MCG) limit weight for temperature adjusted field length and pressure altitude.
4. Max allowable slippery runway limited weight is lesser of weights from 1 and 3.
June 07, 2002
