Operation
BOMAG46 BMP 8500
Fig. 66
l Turn the ignition key (Fig. 66) to position "0".
Transmitter and engine will be switched off after
two seconds, the green control light on the trans-
mitter goes out.
Fig. 67
l Switch off and pull out main battery switch 1
(Fig. 67).
l Plug the safety cap on the lock.
Fig. 68
l Pull off the ignition key (Fig. 68) and store it in
a safe place.
If the power pack of the remote control is to be re-
charged via the remote control cable, the main
battery switch (Fig. 67) must be switched on.
Cleaning after use
Keep the radio remote control clean.
Rests of concrete, clay or mortar may damage
the bellows on travel levers and sealing caps
on toggle switches, so that water can enter.
Do not use a water jet or a high pressure or
steam cleaner for cleaning.
l After work clean the transmitter with a clean
cloth or brush.
l Check the state of bellows and sealing caps at
regular intervals, have replaced by an expert,
if necessary.
