Bomag BMP 8500 - Charging the Power Pack with the External Battery Charger

Operation
BOMAG48 BMP 8500
Charging the power pack with the ex-
ternal battery charger
Fig. 71
l Switch off the transmitter (Fig. 71) with the ig-
nition key.
Fig. 72
l Press the power pack forward and lift it out of
the housing (Fig. 72).
Fig. 73
l Push lock 1 (Fig. 73) on the mains unit of the
battery charger forward and pull plug (2) up-
ward out of the mains unit.
Fig. 74
l Plug the corresponding plug (Fig. 74) onto the
mains unit of the battery charger.
i
Note
The type of plug to be chosen depends on the
country. Observe local conditions and regulations.
