As required
BOMAG90 BMP 8500
Fig. 135
l Pull the filter element (Fig. 135) carefully out of
the housing.
Avoid contact between filter element and
housing.
Fig. 136
l Clean the sealing face on the outlet tube (Fig.
136).
Dust on the outer diameter of the outlet tube can
impair effective sealing.
Fig. 137
l Thoroughly clean the inside of the outlet tube
(Fig. 137) and the filter housing.
Dirt that may incidentally drop into the outlet tube
will reach the engine and cause wear.
l Check the old filter element.
The old filter element can be of help to discover
foreign particles on the sealing face, which could
lead to leaks. A dust strip on the clean air side of
the filter may be a sign for thisEliminate the prob-
lem before installing a new filter element.
l Clean or replace the filter element.
l Examine the filter element thoroughly for dam-
age.
Before installing the new filter element check it for
possible damage from transport, cleaning or incor-
rect handling. Especially on the inside of the open
end (sealing area). Do not install a damaged filter
element.
Fig. 138
l Insert the filter element (Fig. 138).
