Front panel
10 of 29
JUD408312 Rev.B JSE410920 22/07/08
< MEASURES >
AC/DC
DC measures. It is accessed
pressing the key (see 3.3.5),
pressing the keys or the
other sub-menu are scrolled
down.
< MEASURES >
BATTERY
BATTERY measures. It is
accessed pressing the key
(see 3.3.6), pressing the keys
or the other sub-menu are
scrolled down.
< MEASURES >
EXIT
Pressing the key the main
menu screen is shown, pressing
the keys or the other sub-
menu are scrolled down.
NOTE
In the following paragraphs the sub-menu will be always represented as shown in the
3Ph UPS systems; the voltage measures are always referred to the phase-to-neutral
value.
The structure of the sub-menu for the 1Ph systems remains exactly the same, but the
screens and the parameters are slightly different.
