Front panel
Rev.B JSE410920 22/07/08 JUD408312
11 of 29
3.3.1 Input
INPUT VOLT/CURR
XXX YYY ZZZ V
xx.x yy.y zz.z A
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
INPUT FREQUENCY
XX.X Hz
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
INPUT POWER
XXXXX W
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
POWER FACTOR
X.XX
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
< INPUT >
EXIT
Pressing the key leads to the
ME
A
SURES menu screen (see
3.3), pressing the keys
or
the measures are shown again.
