Front panel
Rev.B JSE410920 22/07/08 JUD408312
15 of 29
3.3.6 Battery
BATTERY VOLT/CURR
POS: XXX V xx.x A
NEG: YYY V yy.y A
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
BATTERY TYPE
XXX Ah
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
BATTERY AUTONOMY
XXX min
YY %
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
< BATTERY >
EXIT
Pressing the key leads to the
MEASURES menu screen (see
3.3), pressing the key or the
measures are shown again.
