Front panel
Rev.B JSE410920 22/07/08 JUD408312
19 of 29
3.4.3 List of alarms and status
List of alarms List of status
A1 MAINS FAULT S1 BOOSTER OK
A2 INPUT WRONG SEQ
A3 BOOSTER STOPPED
A4 BOOSTER FAULT
A5 DC VOLTAGE FAULT
A6 BATTERY IN TEST S2 BATTERY OK
A7 BCB OPEN
A8 BATTERY DISCHAR
A9 BATTERY AUT END
A10 BATTERY FAULT
A11 SHORT CIRCUIT S3 INVERTER OK
A12 STOP MAX CURRENT
A13 INV OUT TOLERAN
A14 BYPASS WR SEQUEN (**)S4 INV FEED LOAD
A15 BYPASS FAULT S5 INVERTER SYNCHRO
(**)A16 BYPASS Æ LOAD S6 BYPASS OK
A17 RETRANFER BLOCK (*) S7 BYP Æ LOAD
A18 MBYP CLOSE
A19 OCB OPEN
A20 OVERLOAD
A21 THERM IMAGE
A22 BYPASS SWITCH
A23 EPO PRESSED
A24 HIGH TEMPERATURE
A25 INVERTER OFF
A26 SSCI COM FAULT
A27 EEPROM ERROR
A28 UPS CRITICAL FAULT
A29 MAINTENANCE REQ
A30 COMMON ALARM
A33 ASYMMETRIC LOAD
A34 SERVICE REQ
(*)A38 INV Æ LOAD
(*) Active in ECO-MODE
(**) Not active in ECO-MODE
The status shown in this list are always displayed in ascending order when the
STATUS menu is entered, the alarms are shown when they are present and must be
silenced with the buzzer. The alarms remain displayed whilst they are present and they
are automatically stored in the event history memory with date and time.
