Front panel
Rev.B JSE410920 22/07/08 JUD408312
25 of 29
3.6.2 DEVICE Type
< DEVICE Type>
3/3
It indicates UPS’ input /output.
You can see if the l’UPS is
Threephase/ Threephase 3/3 or
Threephase / Singlephase 3/1.
Pressing you can enter the
next parameter; pressing you
can come back to the previous
menu
< DEVICE Type >
ON-LINE
It indicates the UPS topology:
ON-LINE
ECO-MODE
FREQ CONVERTER
Pressing you can enter the
next parameter; pressing you
can come back to the previous
menu
< DEVICE Type >
SINGLE
It indicates the UPS configuration:
Parallel or Stand Alone
Pressing you can enter the
next parameter; pressing you
can come back to the previous
menu
< DEVICE Type >
EXIT
Pressing you can come back to
INFO menu (see 3.6), pressing
or you can see the
measurements.
