Borri B8031 - UPS Parallel Communication Monitoring; Monitoring Parallel CAN-BUS and Synchronization Messages

Front panel
Rev.B JSE410920 22/07/08 JUD408312
27 of 29
< PARALLEL >
CAN B MSG: XXXXX
It indicates, for the paralell
system, the number of packets
recevied through the channel B of
the CAN-BUS.
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
< PARALLEL >
SYNC MSG: XXXXX
It indicates, for the paralell
system, the number of
synchronisation messages
recevied through the channel A of
the CAN-BUS.
Pressing the key the following
parameter is shown, while the key
leads to the previous screen.
< PARALLEL >
EXIT
Pressing you can come back
to INFO menu (see 3.6), pressing
or you can see the
measurements.
