HID reader LED indicators
HID reader LED Buzzer
Armed.The zone is
Armed
Red Off or Beeping During Arm
Delay
Part ArmedThe zone is
Armed with some Input
Point(s) bypassed. Card
is presented to the
Reader when the LED is
flashing.
Green/Red Alternating at slow
rate
Off or Beeping During Arm
Delay
Ready/DisarmedAll Input
Points in the zone are in
the Normal state and are
ready for Arming.
Green Off
Not Ready/DisarmedOne
or more Input Points is
not in the Normal state
and not ready for Arming
Green/Red Alternating at
medium rate
Off
AlarmThe zone is Armed
and one or more Input
Point is in Alarm State
Red 0.5 sec. On and 0.5 sec. Off
*Slow flashing is at around 1 sec. ON then 1 sec. OFF interval; whereas normal flashing is at ½
sec. interval.
The LED besides being used to indicate an alarm condition in the zone is also used during the
Arming process.
When you arm the Alarm Zone, the LED will flash for the duration as depicted in the Arm Delay
field of that particular Alarm Zone. We provide a few example below for further understanding.
Configuration in the AEC2.1
– Input Points #1, 2, 3, and 4 are grouped as Alarm Zone #1.
– Arm Delay = 15 seconds.
– Alarm Delay = 0 seconds
– Reader #4 is the Arm/Disarm Reader for Alarm Zone #1.
– Some cards are given the access rights to arm/disarm Alarm Zone #1. No PIN code
required.
Arming an Alarm Zone
Example 1 - All Input Points are in the Normal state.
1. LED has a stable green light.
2. Press 0 key and present the arming card to Reader #4.
LED turns to red light.
