5.1 Component Layout of the CPU Board
The following layout diagrams shows the major physical components on the CPU board. A
brief description is provided on some of the major components.
There are three different types of CPU boards, hence the layout of each type will be slightly
different. The diagrams below shows each type and the location of the relevant components.
Figure5.2: Type1 CPU Board
Figure5.3: Type2 CPU Board
