Part IV: Multi-Area Use
View Point Status
D1260 Owner’s Manual
50410C © 2003 Bosch Security Systems
7. After pressing the Status> key, the command center
will display the following information:
Definitions:
Line 1 Area name
Line 2 Area #, Pt # Area # - This may display numbers 1 through 8.
Pt # - This may display point numbers 1-127 and 129- 247,
Line 3 <Point State), HW Normal – indicates that the point is not in the faulted state.
Open – indicates that the point is in an open state.
Short – indicates that the point is in a shorted state.
Missing – indicates that the point is missing.
