14 en | In overview
FPA-5000 | FPA-1200 | AVENAR panel 8000 |
AVENAR panel 2000 | AVENAR keypad 8000
2020-07 | 3.0 | F.01U.378.877 User Guide Bosch Sicherheitssysteme GmbH
Log in and out: Enter user ID and password or call up personalized
menu, if you are already logged in.
Temporarily silence the internal buzzer.
"Left arrow" key. Move the cursor one place to the left on the search
screen.
"Right arrow" key. Move the cursor one place to the right on the search
screen.
"Double arrow" key. Switch between status bars if two or more are
available. Call up the status bar to scroll rapidly through lists.
"Enter" key. Confirm an alphanumeric entry. Confirm an entry that is
not confirmed by selecting the OK field on the touch screen.
Alphanumeric keypad
Entry of letters, special characters, and numbers.
Function keys
There are three function keys F1, F2 and F3 which are freely programmable with frequently
used functions of the panel via the Programming Software. If a function key is active it is
marked with a green bar.
Alphanumeric keypad
Entry of letters, special characters, and numbers.
4.2 Status LEDs
18 status LEDs show information on the operating status of the fire panel.
Color* Meaning
R Fire alarm
R Evacuation ongoing
R Fire alarm transmission activated
R Fire protection equipment activated
Y Maintenance mode
Y Day mode/delays active
