1. Bypass Block
2. Bypass
3. Detector
Three sorting criteria are offered for selection:
– By description
– By number
– By number (no description shown)
4 Select By description.
A list of all detectors is displayed, sorted in alphabetical order.
5.7.1 Scrolling through lists
On the display, only a limited number of list fields can be displayed.
Select the "up arrow" key to scroll back through a long list:
Select the "down arrow" key to scroll forward through the list:
An arrow is only displayed if scrolling is possible.
Rapid scrolling:
To scroll quickly through a list, press the "double arrow" key on the membrane keypad or on
the status bar of the display.
A scrollbar appears on the status bar:
Gently touch the horizontal line to jump to a particular place.
To jump to the beginning of a list, touch:
To jump to the end of a list, touch:
5.7.2 Various states of list fields
Various states can be assigned to an element or an element group, depicted by a list field. The
following table provides information about the possible states:
List field State of list
field
Meaning
TEXT
normal Element in normal state
TEXT
marked Selected element
TEXT
Mode assigned The element was assigned the bypassed mode;
seeAssigning mode, page 28.
