54 en | Fault message Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
Notice!
The information displayed is entered in the FSP-5000-RPS programming software.
The following information is displayed:
– Element category
– Message type
– Date and time of the message
– Physical and logical addressing of the element
– Only for LSN detectors: specification of the detector type
– Action text (depending on the configuration)
Select OK to return to the list of all fault messages. Reset, see Resetting malfunction message,
page 54.
Block, see Isolating an element, page 55.
11.2.8 Signals
Optical signals
An internal buzzer sounds on the panel and the "fault" signal light turns yellow.
Depending on the type of fault, an additional yellow signal light lights up (see also Display
elements, page 20):
– Fault System
– Fault Transmission Device
– Fault Signals
Acoustic signal
An internal signal tone sounds on the system.
To temporarily switch off the internal buzzer:
Press the "Signal tone off" key.
The internal signal tone is switched off.
11.3 Resetting malfunction message
Caution!
If a message does not have to be reset, it is removed from the display as soon as the fault has
been rectified.
Depending on the configuration, three different variants are offered for resetting; see Resetting
alarm message, page 49.
There are two ways to reset a fault message:
– Select Reset in the message display or
– Select the fault message and then press Reset in the detailed view
The selected element/element group is reset.
If a list field is marked with an "R", the process of resetting is not yet complete for this
element.
TEXT R
If an element cannot be reset, it will continue to be displayed in the list.
