Bosch MPC-C Series User Manual

64 en | Diagnostics Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
4. Adjust touch screen
5. Carry out the steps shown on the display.
14.4.3 Serial Interface
Select Serial interface to display the statistical data for the transmission.
14.4.4 CAN-Bus
Select CAN bus to display the status of the CAN interfaces.
14.5 Panel Passport
Select Panel passport to display the following diagnostic information:
– Module
– Address
– CAN ID
– Production date
– BOM revision
– PCBA material number
– Material number
– Software version
– Build type
– Build number
– MAC Addresses
14.6 LED Test on modules
To test the LED display of selected modules:
1. In the start menu, select Diagnostics
2. LED test on modules
A list of various selection criteria is offered:
– Select LED test all modules to test the LED display of all modules.
– Select By number or By type to test the LED display of individual selected modules.
Example
To test the LED displays of an LSN 300 module:
1. Select By type.
A list of all module types is displayed.
2. Select the LSN 300 module.
A list of all LSN 300 modules is displayed.
3. Select the list field(s) you require. The list fields are marked.
4. Select Activate LEDs.
The LEDs are activated for the duration of approx. five seconds.
Notice!
The numbers before the module names indicate the slot of the module on the panel.
14.7 Network services
14.7.1 Routing table
To display routing information:
