en | Fire alarm
Panel Controller
2017.09 | 7.0 | F.01U.258.929
User Guide
Bosch Sicherheitssysteme GmbH
1.
Select the alarm message you require.
2.
Select
Bypass
.
Notice!
The system does not transmit any information as to whether it was possible to bypass the
selected element. To monitor the operation, please check the element.
49
51
Table of Contents
Table of Contents
3
For Your Information
8
Open Source License Agreement
8
Depiction of Steps
8
Calling up the Start Menu
9
Changing Language Display
9
Warranty and Liability
9
Copyright
9
For Your Safety
10
Symbols and Notes Used
10
Operating the Touch Screen
10
Maintenance
10
Usage in Accordance with Regulations
11
Skills Required by Personnel
11
All Functions at a Glance
12
Calling up the Start Menu
12
Bypass/Isolate
12
Bypass
12
Isolate
12
Diagnostics
13
Maintenance
14
Walktest
14
Change Language
15
Activate Outputs
15
Activate the Transmission Device
15
Detector Removal
15
History Log
15
Change Device on V.24 Interface
16
Configuration
16
Switching to Day or Night Mode
17
Further Functions
17
Search Function/Element
18
Reset
18
In Overview
19
Operating Elements
19
Display Elements
20
Touch Screen
21
Display Support Information
23
Operating Principle
24
Logging on and off
24
Logging in
24
Logging out
25
Access Authorization
25
Calling up the Start Menu
25
Personalized Menu
25
Selecting the Menu
26
Returning to the Previous Selection
26
Working with Lists
26
Various States of List Fields
27
Scrolling through Lists
27
Selecting Element/Function
28
Assigning Mode
28
Search Function/Element
29
Search by Name
29
Searching by Number
29
Entering Numbers and Text
29
Changing an Entry
31
Deleting All Numbers
31
Changing Language Display
31
Entering Key Combination
31
Switching between Status Bars
31
Standby
31
Logical and Physical Addressing
31
Networked Panels
33
Icons on the Display
33
Network Addressing
33
Establishing a Remote Connection with a Networked Panel
34
Terminating a Remote Connection with a Networked Panel
34
Isolating and Restricted Connection
34
Networking Via Ethernet
36
IP Settings
36
Ethernet Redundancy
37
Diagnostics
38
Remote Keypad
39
Operation and Display
39
Alarm
40
Types of Alarm
40
Entry Delays
40
Day and Night Mode
41
Alarm Message to the Panel
42
Optical and Acoustic Signals
42
Displaying the Detector Zones in Alarm State
42
Sequence of the Alarm Messages
43
Information about Logical Zones in the Alarm State
43
The Newest Message
44
Displaying the Individual Detectors in a Logical Zone
44
Information about Individual Detectors
44
Displaying Additional Information
45
Fire Alarm
46
Optical and Acoustic Signals
46
Acknowledging a Message
46
Switching off Internal Buzzer
46
Switching External Signaling Devices on and off
47
Resetting External Signaling Devices and Transmission Devices
47
Triggering Fire Verification
47
Alarm Verification
47
Starting Time to Investigate
48
Triggering Alarm Manually
48
Resetting Alarm Message
49
Bypassing Detectors
49
Fault Message
51
Calling up Fault Indication
51
Trouble Message on the Panel
51
Acknowledging a Message
51
Sequence of the Trouble Messages
52
Information about Malfunctioning Element Groups
52
The Newest Message
53
Displaying Individual Elements of an Element Group
53
Information about Individual Elements
53
Displaying Additional Information
53
Signals
54
Resetting Malfunction Message
54
Isolating an Element
55
Bypass
56
Menu Overview
56
Bypassing and Un-Bypassing Elements
56
Displaying and Un-Bypassing Bypassed Element Groups
57
Displaying List of All Bypassed Elements
57
Using the Menu
57
Via the Status Bar
58
Bypassing/Un-Bypassing Buzzer
58
Isolate
59
Menu Overview
59
Isolating and De-Isolating Elements
59
Displaying List of All Isolated Elements
59
Using the Menu
60
Via the Status Bar
60
Diagnostics
61
Menu Overview
61
Element Details
61
Modules
62
Hardware
62
Address Cards
62
Display
62
Serial Interface
64
CAN-Bus
64
Panel Passport
64
LED Test on Modules
64
Network Services
64
Routing Table
64
Consistency Check
65
Ethernet Ports
65
Send Ping Command
66
Ethernet Redundancy
66
Remote Services
67
Voice Alarm Systems
68
Menu Overview
70
Changing Language Display
70
Activate Outputs
70
Maintenance
70
Activate Transmission Device
71
Detector Removal
71
Change Device on V.24 Interface
71
Bypassing/Un-Bypassing Buzzer
72
Maintenance - Walktest
73
Walktest Groups
73
Adding or Deleting Elements
73
Starting and Ending Walktest
75
Starting the Walktest
75
Ending the Walktest
75
Ending Walktest for All Elements
75
Displaying Tested or Untested Elements
76
Assigning Tested Elements to a Walktest Group
76
Maintenance - History Log
77
Selecting Filters
77
Setting Filters
77
Change Filter
78
Combining Several Filters
78
Status Bar Functions
78
Printing out Data
79
Day and Night Mode
80
Switching between Day and Night Mode
80
Showing Details
81
Changing the Time for Resetting to Night Mode
81
Configuration
83
Menu Overview
83
Input / Output Group Set up
83
Adding or Deleting Elements
83
Change Name
85
Group Setting
85
Adding or Removing
85
Detector Sensitivity
85
Operator
86
Change Password
86
Change Universal Password
86
Set Default Password
87
Rename Elements
87
Network Services
87
Ethernet
87
Change Date/Time
87
Remote Services
87
Overview
88
Enter the Master Password that Is Valid Indefinitely
89
Further Functions
89
Menu Overview
89
Change Date / Time
89
Master Password
89
Enter the 24-Hour Master Password
90
Remote Services
90
Change Password
91
Performing a Fire Drill
91
Alarm Counters
92
Reset
93
Menu Overview
93
Resetting Elements
93
Search Function/Element
94
Menu Overview
94
Searching for Function and Device Description
94
Search Element
94
