84 en | Configuration Panel Controller
2017.09 | 7.0 | F.01U.258.929 User Guide Bosch Sicherheitssysteme GmbH
Output group
To display the elements in an output group and to delete or add elements, repeat the steps
shown in the example for the input group (Adding or removing, page 85) but select Output
group in step 3.
Toggle function
New elements can be added and existing elements deleted in every submenu.
When one of the function fields is selected, the display changes and a new function can be
performed.
Add
+
New
Select this function field to add one or more new elements.
Only those elements that have not yet been assigned to an input group will be displayed.
Various element categories are displayed.
1. Select the category you require.
A list of elements is displayed. See also Working with lists, page 26.
2. Select an element.
The element is marked.
3. Select Add.
The selected element is added to the group.
Delete
-
Old
Select this function field to delete one or more elements.
Only elements from the selected input group are displayed.
1. Select an element.
The element is marked.
2. Select Delete.
The selected element is deleted from the group.
Example:
1. Select Show / Change.
To delete one or more element(s) from the selected group:
2. Select one or more list fields.
The list fields are marked. Refer to Scrolling through lists, page 27 for information on how
to navigate through a list.
3. Select Delete.
The element is deleted from the selected group. The list field is no longer displayed.
In order to add new elements:
1. Select New.
The display changes. Various element categories containing elements which have not
been assigned to any walktest group yet are displayed.
2. Select the element category you require.
3. Select one or more list fields.
The list fields are marked.
4. Select Add.
The selected element is added to the selected walktest group.
