Legend device interconnections
Icon Description Link to wiring section
MPS3 Network port 1‑2 with PoE Power over Ethernet, page 75
48VDC output A‑B (1‑3, to amplifier 1‑3) Amplifier power supply, page 72
Power supply, page 49
Lifeline interface (1‑3, to amplifier 1‑3) Lifeline, page 73
Lifeline, page 50
General network port Ethernet network, page 54
Ethernet network, page 76
Ethernet network, page 31
Loudspeaker output Amplifier outputs, page 51
Mains input Mains power connection, page 71
Battery 12VDC Battery and fuse, page 67
24VDC output A‑B
(to system controller)
System controller power supply,
page 74
Power supply, page 30
Control input 1‑8 Control inputs, page 78
Control output 1‑8 Control outputs, page 79
