3.8 LCD call station | PRA-CSLD, PRA-CSLW
PRA-CSLD PRA-CSLW
3.8.1 Connections
Figure3.11: Bottom view wiring connections
Network port 1-2 (PoE
PD)
Local source audio line
input
PRA-CSE
interconnection
