3 609 929 408/2.1 | LTH Electric Drives and Controls | Bosch Rexroth AG 35/60
2 Power Unit LTH
2 Power Unit LTH
2.1 Technical Data
LTH 230 V LTH 110 V
Protection type IP 42 IP 42
Class of protection I (protective grounding) I (protective grounding)
EMC level 4 according to IEC 801 level 4 according to IEC 801
Operating voltage 220V - 240V / 50Hz - 60Hz ±10% 100V - 110V / 50Hz - 60Hz ±10%
Current max. 10A max. 20A
Power consumption 400VA 400VA
Operating temperature 0°C … +50°C 0°C … +50°C
Storage temperature -20°C … +70°C -20°C … +70°C
Humidity 20 % up to 90 % non-condensing 20 % up to 90 % non-condensing
Output voltage 0 - 230V 0 - 230V
Nominal output current 2A 2A
Max. output current 12A 12A
Output frequency 0 - 500Hz 0 - 500Hz
Dimensions:
Length 310 mm 310 mm
Width 160 mm 160 mm
Height 310 mm 310 mm
Weight 13.4 kg 13.4 kg
Counter
Data retention through 2 batteries: 8 years at 5·10
5
power operations of the output relay and an
ambient temperature of 25 °C
Batteries 2 pieces Type
1
/
2
AA Lithium 3.6 V
Table 1:
