Bosch Rexroth LTH - Location of Plugs on Lower Side

46/60 Bosch Rexroth AG | Electric Drives and Controls LTH | 3 609 929 408/2.1
2 Power Unit LTH
2.8 Location of Plugs on Lower Side
Fig. 8: Bottom View
78
Frontplatte
2
3
4
5
6
1
1 Motor connector (X3)
2 User interface (X13)
3 Sensors (X2)
4 BMS-interface (X7)
5 Command line (X8)
6 IEC receptacle (power line output)
7 Power line switch
8 IEC connector (power line input)
Front panel
