54/60 Bosch Rexroth AG | Electric Drives and Controls LTH | 3 609 929 408/2.1
2 Power Unit LTH
2.10.4 Stock Control SE200 (X7)
SUB-D-connector, 37-pins, female
Fig. 14:
Pin-No. Signal Input/Output
(I/O)
Description/Function
1 - N.C.
2 PRG4 O Program selection SE200, bit 3
3 NIOQ O Acknowledgement NIO bolting action
4 - N.C.
5 0V Hand-held power tool reference potential
6 BMIO O Options module ready
(permanently applied to +24V)
7 SSR O Power tool start right (tighten)
8 - N.C.
9 PRG1 O Program selection SE200, bit 0
10 PRG3 O Program selection SE200, bit 2
11-14 - N.C.
15 NIO I Bolt process not in order
16 - N.C.
17 FA I Color
18 24VSE Power supply from control
19 OV Hand-held power tool reference potential
20-24 - N.C.
25 TA O Test sequence (SF reset)
26 - N.C.
27 SLL O Search run left (unbolt)
28 PRG2 O Program selection SE200, bit 1
29-32 - N.C.
33 IO I Bolt process in order
34 /SF I System error SE200 (low active)
35 AE I End of action from SE200
36 24VSE Supply from control
37 - N.C.
Table 6:
