Bosch Rexroth LTH - Stock Control (X11), Option; User Interface (X13)

3 609 929 408/2.1 | LTH Electric Drives and Controls | Bosch Rexroth AG 57/60
2 Power Unit LTH
2.10.7 Stock Control (X11), Option
SUB-D connector, 15-pins, male
Fig. 17:
NOTE: Interface X11 must not be used for power tool operation. User interface X13 on the lower side
of the LTH is available for external signals.
2.10.8 User Interface (X13)
SUB-D-connector, 15-pins, male
Fig. 18:
Pin-No. Signal Input/Output
(I/O)
Description/Function
1 0V Reference potential for hand-held
power tool
2 BTBR O Current control ready for operation
3 AE O Sequence end from ST
4 QPG1 O Program selection acknowledgement
5 /SF O Current control system error (low active)
6 GSBR O Group start ready
7 TA I Test sequence (SF reset)
8 24VBMS Power supply for PLC interface
9 TIEF I Depth
10 LLP I No-load test
11 NIO O Bolt process not in order
12 IO O Bolt process in order
13 PGR1 I Current control program selection
14 SLL I Search run left
15 SSR I Power tool start right
Table 9:
81
159
☞
Pin-No. Signal Input/Output
(I/O)
Description/Function
1 0VBS Reference potential for user interface X13
2 PRG4 I Program selection SE200, bit 3
3 AE O End of sequence
4 FA O Color
5 /SF O System error (low active)
6 SIO O Output IO sums counter
7 TA I Test sequence (SF reset)
8 24VBS Supply for user interface X13
9 PRG3 I Program selection SE200, bit 2
10 LLP I No-load test request
11 NIO O Bolt process not in order
12 IO O Bolt process in order
13 PGR1 I Program selection SE200, bit 0
14 SIORES I Reset IO sums counter
15 PRG2 I Program selection SE200, bit 1
Table 10:
81
159
