6 | Password protected menu (advanced functions) Weighing Terminal EWI /
P08
CAL
p08-03
nU-U
FIELO
Theoretical calibration
Sens
“3.0000“ mV/V flashes
--> Enter the value.
(Setting the sensitivity of
the load cells used). If
several load cells are
connected in parallel to
one channel, the average
value must be entered!
TCAP
“1000.0“ kg flashes -->
Enter the value.
(Setting the maximum
load of the load cells
used). If several load
cells are connected in
parallel to one channel,
enter the sum of all con-
nected load cells, taking
into account the decimal
places "dEcI" (P07-01).
Example
:
4 load cells á 1000 kg =
4000 kg (dEcI= 0.0) -->
4000.0
ST2AP
UnLoad
Set the zero point.
p08-04
GrAUTY
OFF
„9.81300“ flashes --> Set the
gravity value.
Adaptation of the gravity
factor to correct the
weight value on the site
of scales use. (Default:
9.8130)
Menu Submenu Option Function
