24
ELECTRICAL PART LIST
Diodes
Transistors
Integrated Circuits
Miscellaneous
ESP-00 II Motherboard PCB Assembly (Rev. B)
Reference
Designator
Description
V
endor Part Number
V
endor Name Note
D201 OPEN NOT USED NOT USED
D202 1SR154-400 1SR154-400 RHOM
D207 1SR154-400 1SR154-400 RHOM
D208 1SR154-400 1SR154-400 RHOM
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
Q100 DTA114EK
A
DTA114EKA RHOM
Q101 OPEN NOT USED NOT USED
Q202 2SB1122S 2SB1122S SANYO
Q203 DTC114EKA DTC114EKA RHOM
Q205 DTC114EKA DTC114EK
A
RHOM
Q211 DTA114EKA DTA114EKA RHOM
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
M100 74VHC138A TC74VHC138FT TOSHIBA
M104 74VHC138A TC74VHC138FT TOSHIBA
M200 uPC2933T uPC2933T NEC
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
CN100 87BMN-030SF 87BMN-030S KEL
CN101 87BMN-030SF 87BMN-030S KEL
CN102 87BMN-030SF 87BMN-030S KEL
CN103 87BMN-030SF 87BMN-030S KEL
CN104 87BMN-030SF 87BMN-030S KEL
CN105 87BMN-030SF 87BMN-030S KEL
CN106 87BMN-030SF 87BMN-030S KEL
CN107 87BMN-030SF 87BMN-030S KEL
CN108 87BMN100S 87BMN-100S KEL
CN200 B6P-VH B6P-VH NICHIATSU
CN202 B8B-XH B8B-XH NICHIATSU
CN203 B8B-XH B8B-XH NICHIATSU
CN204 B8B-XH B8B-XH NICHIATSU
CN205 B3B-XH B3B-XH NICHIATSU
