Bose ControlSpace ESP-00 II - Page 25

25
ELECTRICAL PART LIST
Resistors
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R100 100
k
RK73H1JTD100kF KOA
R101 100 Ohm RK73H1JTD100RF KOA
R102 100 Ohm RK73H1JTD100RF KOA
R103 100k RK73H1JTD100kF KOA
R104 OPEN NOT USED NOT USED
R105 6.8k RK73H1JTD6.8KF KOA
R106 6.8k RK73H1JTD6.8KF KOA
R107 OPEN NOT USED NOT USED
R108 6.8k RK73H1JTD6.8KF KOA
R109 6.8k RK73H1JTD6.8KF KOA
R110 1.3k RK73H1JTD1.3KF KOA
R111 OPEN NOT USED NOT USED
R112 5.1k RK73H1JTD5.1KF KOA
R113 OPEN NOT USED NOT USED
R114 OPEN NOT USED NOT USED
R115 82 Ohm RK73H1JTD82RF KOA
R116 OPEN NOT USED NOT USED
R117 68 Ohm RK73H1JTD68RF KOA
R118 OPEN NOT USED NOT USED
R119 OPEN NOT USED NOT USED
R120 1.3k RK73H1JTD1.3KF KOA
R121 OPEN NOT USED NOT USED
R122 5.1k RK73H1JTD5.1KF KOA
R123 OPEN NOT USED NOT USED
R124 OPEN NOT USED NOT USED
R125 82 Ohm RK73H1JTD82RF KOA
R126 OPEN NOT USED NOT USED
R127 68 Ohm RK73H1JTD68RF KOA
R128 560 Ohm RK73H1JTD560RF KOA
R129 240 Ohm RK73H1JTD240RF KOA
R131 680 Ohm RK73H1JTD680RF KOA
R132 680 Ohm RK73H1JTD680RF KOA
R133 680 Ohm RK73H1JTD680RF KOA
R134 680 Ohm RK73H1JTD680RF KOA
R135 680 Ohm RK73H1JTD680RF KOA
R136 680 Ohm RK73H1JTD680RF KOA
R137 680 Ohm RK73H1JTD680RF KOA
R138 680 Ohm RK73H1JTD680RF KOA
R139 560 Ohm RK73H1JTD560RF KOA
R140 240 Ohm RK73H1JTD240RF KOA
R141 39k RK73H1JTD39KF KOA
R142 39
k
RK73H1JTD39KF KOA
R143 39k RK73H1JTD39KF KOA
R144 10k RK73H1JTD10KF KOA
R145 10k RK73H1JTD10KF KOA
R146 6.8k RK73H1JTD6.8KF KOA
4x4 Series II PCB Assembly (optional on ESP-00 II)
