ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R147 12
k
RK73H1JTD12KF KOA
R148 6.8k RK73H1JTD6.8KF KOA
R149 12k RK73H1JTD12KF KOA
R150 12k RK73H1JTD12KF KOA
R151 6.8k RK73H1JTD6.8KF KOA
R152 6.8k RK73H1JTD6.8KF KOA
R153 12k RK73H1JTD12KF KOA
R156 12k RK73H1JTD12KF KOA
R157 6.8k RK73H1JTD6.8KF KOA
R158 6.8k RK73H1JTD6.8KF KOA
R159 12k RK73H1JTD12KF KOA
R160 12k RK73H1JTD12KF KOA
R161 6.8k RK73H1JTD6.8KF KOA
R162 12k RK73H1JTD12KF KOA
R163 6.8k RK73H1JTD6.8KF KOA
R164 10
k
RK73H1JTD10KF KOA
R165 10k RK73H1JTD10KF KOA
R166 39k RK73H1JTD39KF KOA
R167 39k RK73H1JTD39KF KOA
R168 39
k
RK73H1JTD39KF KOA
R169 4.7k RK73H1JTD4.7KF KOA
R170 1.8k RK73H1JTD1.8KF KOA
R171 1.2k RK73H1JTD1.2KF KOA
R172 4.7k RK73H1JTD4.7KF KOA
R173 4.7k RK73H1JTD4.7KF KOA
R174 1.8k RK73H1JTD1.8KF KOA
R175 1.2k RK73H1JTD1.2KF KOA
R176 4.7k RK73H1JTD4.7KF KOA
R200 100k RK73H1JTD100kF KOA
R201 100 Ohm RK73H1JTD100RF KOA
R202 100 Ohm RK73H1JTD100RF KOA
R203 100k RK73H1JTD100kF KOA
R204 OPEN NOT USED NOT USED
R205 6.8k RK73H1JTD6.8KF KOA
R206 6.8k RK73H1JTD6.8KF KOA
R207 OPEN NOT USED NOT USED
R208 6.8k RK73H1JTD6.8KF KOA
R209 6.8k RK73H1JTD6.8KF KOA
R210 1.3k RK73H1JTD1.3KF KOA
R211 OPEN NOT USED NOT USED
R212 5.1k RK73H1JTD5.1KF KOA
R213 OPEN NOT USED NOT USED
R214 OPEN NOT USED NOT USED
R215 82 Ohm RK73H1JTD82RF KOA
R216 OPEN NOT USED NOT USED
R217 68 Ohm RK73H1JTD68RF KOA
4x4 Series II PCB Assembly (optional on ESP-00 II)
